| Technical Details - Sound Proof Doors |
| |
As per our internal test report we have successful achieved an sound rating of 41 to 59db available STC-54 FLUSH
Communicating doors, Two STC-40 Doors Installed
back-to-back in common frame.
Double 300 series bottom seal & top seal for each door.
(1220 x 3050 mm), wood or high pressure decorative
laminate faced. |
| |
100% Noise Reduction?
While Soundproof Windows/door cannot eliminate 100% of the noise, it will be reduced very significantly. Less noise will be coming through the Soundproof Windows/door than the walls in many cases. Most walls are an STC 42-43: Soundproof Windows usually have an STC rating of 45-54. Several things can be done to increase the STC rating even more. |
| |
All KSC Acoustical Doors are 1 3/4” (44 mm) thick and may be used with normal hardware in standard hollow
metal frames (back-filled). STC-28 doors weigh the same as most regular solid core doors while the STC-39
through STC-45 doors are slightly heavier. Door weight and usage should be considered when selecting frames
and hardware. Full mortise hinges and either cylindrical or mortise type locks may be used. The maximum
Benefit of acoustical doors is provided from openings with uniform door/frame edge clearance, correct
positioning of gasket, and proper adjustment of the automatic bottom seal. |
| |
BTU Losses and Insulation Values *
|
Insulation
Values |
BTU Loss Per Month |
|
Inside
Temperature 70° F |
R
Value |
U
Value |
Average Outside Temperature |
Window Description |
|
(1/R) |
40° F |
30° F |
Pct
Reduction |
Single pane glass |
1.15 |
0.869 |
2,981,000 |
3,971,000 |
0% |
Dual pane glass with 1/2" air space |
1.81 |
0.55 |
1,426,000 |
1,901,000 |
53% |
Insulating Soundproof Window over single pane window with 1.5" air space |
3.84 |
0.26 |
674,000 |
899,000 |
77% |
Insulating Soundproof Window over dual pane window with 1.5" air space (estimated) |
4.40 |
0.23 |
600,000 |
800,000 |
80% |
|
* Does not include air infiltration losses. BTU loss calculations based on average home with 120 square feet of glass. |
| |
|
|
|
 |
 |
|
|
|
|
| |
|
